Standard Pulp Disintegrator

Standard: ISO 5263, SCAN C18/M2, TAPPI T205
Equipment for the desintegration of pulp suspension. Made entirely in stainless steel. Stainless stell and acrylic transparent pot to see the desintegrator evolution.

Laboratory Pulper

Stainless Steel equipment to de-fibration of virgin or recycled pulps. Available in 3 sizes 8, 17 and 45 litres, to work from 30 to 350 grams of pulp and a consistence range between 2 and 7%. Rotor speed adjustable up to 1500 revolutions per minute.

Laboratory PFI Mill

Standards: ISO 5264/2, TAPPI T248, DIN-EN 25 264-2, SCAN C24
Laboratory equipment to beat chemical or semi-chemical pulps under standardized conditions. Rapid beating of small amounts of pulp (30 gr.). Beating pressure with weight. Pressing the "Start" button automatically starts the beating program and it stops automatically after reaching the adjusted number of revolutions. Beater roll and container are made of stainless steel.

Valley Beater

Standards: ISO 5 264/1, SCAN C25, TAPPI T200, PAPTAC C2
For beating of pulp under standardized conditions for laboratory purposes.

Schoppler – Riegler Freeness Tester

Standards: ISO 526/7, SCAN C 19M3, Zellcheming Merkblatt V/7/61, BS 6 035/1
For determination of the freeness and the drain ability speed of fibre, ground wood and mechanical pulp.

Schoppler – Riegler Freeness Tester
Standard: ISO 5267/1, SCAN C19/M3, BS 6035/1
It is used to determine the refining degree and the drainage speed of the paper pulps. Pneumatic, manual and digital equipment.

Canadian Freeness Tester

Standards: ISO 5267/2, TAPPI 227, BS 6035/2, SCAN C21
Equipment to measure the refining degree of the paper pulp according to the Canadian method.

Bauer Mcnett Fiber Classifier

Standard: TAPPI T233, SCAN M6, PACTAC C5V

Equipment with 3, 4 or 5 tank units to determine the fibre length of pulp in pulp by classification.

Somerville Shive Content Analyser

Standard: TAPPI T275, UM 242
Equipment to determine the shive content and stickers in pulp.

Pulp Viscosity

Standard: TAPPI T230, ISO 5351/1, ISO 5351/2, SCAN C15, PACTAC G.24P

The Semi-Automatic Pulp Viscosimeter calculates easily and quickly the pulp viscosity in standard conditions. Using Ubbelohde or Cannon Fenske viscometers measuring system as in accordance to the test standards.

De-Watering Pulp Centrifuge

High speed laboratory centrifuge, to centrifuge pulp samples. It has 4 positions of 100ml buckets that can centrifuge 150 grams of pulp. The revolutions can be adjusted from 100 to 14,000 rpmm. Robust equipment with easy water discharge.

Manual Tappi Handshet Former

Standard: ISO 5269/1, SCAN C 26, TAPPI T205
Manual Sheet Former machine. Made of stainless steel or cast iron.

Dynamic Hand Sheet Former Model D7
Dynamic Hand Sheet Former D7 is a revised lab equipment, originally designed to make large sized handsheets of paper. The characteristics of the final sheet are close to industrial paper with regard to the fiber orientation and the bulk.

Hand Sheet Press Model P8
This Hand Sheet Press Model P8 is composed by two hard rubber coated rolls, diameter 120mm, pressed together by two air cylinders. The strongly built housing and frame are designed to make its use very safe and user friendly.

Laboratory Sheet Press

Standards: ISO 5269/1, TAPPI T205, SCAN C26/M5
Pneumatic sheet press to crush pulp moist sheets and paper, under standard conditions.

Laboratory Sheet Press (Pneumatic Type)

Standards: ISO 5269/1, TAPPI T205, SCAN C26/M5

Pneumatic sheet press to crush pulp moist sheets and paper, under standard conditions.

Hand Sheet Dryer Model H9
Lab Scale Curved Hand Sheet Dryer Model H9 is designed for drying various handsheets from circular, square or large sized rectangular handsheets e.g. the 94 x 25 handsheets made with dynamic sheetformer.

Benchtop Hand Sheet Dryer Model H9-B
Benchtop Curved Hand Sheet Dryer Model H9-B is designed for drying various handsheets from circular, square or rectangular handsheets. The handsheet is dryed, catched between the massive curved heating plate and a strongly tightened cotton fabric.

Laboratory Speed Dryer

Standards: ISO 4119,  TAPPI T240

Stainless steel construction with anodised aluminium hot plate ensure precise heat distribution. The temperature can be controlled up to 150°C. Digital display with PID control.

Manual Cobb Tester

Standards: ISO 535, SCAN P12, DIN 53 132, TAPPI T441, BS EN 20535

Compound of a cylinder ( Cód. 090107 ) and a roll ( Cód. 090108 ), to obtain the water absorption in paper and cardboard.

Semi-Automatic Cobb Tester

Standards: ISO 535, SCAN P12, DIN 53 132, TAPPI T441, BS EN 20535

Semi-automatic equipment compound of a roll, a cylinder and a chronometer. It is used to obtain the water absorption of paper and cardboard.
